Fabforge-PX2
- Explore: Food 3d Printing, Bio Ceramics, Bio Gels, Conductive Pastes, Silicone, Clays and much more materials in a Single Machine
- Experience: the future of 3D printing with our paste extrusion technology
- Print the Unprintable: Multi-Material Precision paste extrusion for endless creative possibilities
Machine Specification
Version
Fabforge-PX2
Technology
PEP (Paste Extrusion Printing)
Mechanism
Core-Xy
System
CPPD
Extruders
Dual
Build Size
100x110x110mm (XYZ)
Dual Mode
70x110x100mm (XYZ)
Nozzle Variants
14G-25G/0.1mm - 1.54mm
Head Temperature
Upto 80˚C
Operating Pressure
0-0.6Mpa / 0-6 bar
Head Volume
30cc/55cc Expandable toc500cc
Position Accuracy
X/Y 0.01 mm ; Z 0.02mm
Machine Weight
14 kgs
Package Weight
16 kgs
Foot Print
310x310x390mm
Power
110 V/230V AC,
Consumption
120Watts
Input Format
STL, .3mf
Output Format
G Codes
Warranty
1 year replacement warranty
Service
1 year free Service
Connectivity
Supported Materials -Open source
Ceramics - HAP, Bentonite, Tri calcium Phosphate etc.
Bio Medical - Hydrogels and serum’s.
Food Engineering – Starch, Proteins, Pastries, Chocolates, Cake batters, Millets etc.
Pottery – Porcelain Clays
